Our HMI & Visualisation tools include the following:
- Operator’s HMI
- Process display for AGC and AFC
- Alarms & warnings
- Diagnostics
- Level 2 interface for coil setup
- Recipe data (when no Level 2)
- Production logging reports
- Engineer’s HMI
- Extensive graphical diagnostics screens for each technological function (HGC/AGC/AFC etc)
- Real-time chart recording including FFT display
- Applications software development environment for on-line software analysis.
![HMI example for a reversing 6-Hi copper mill](http://www.tdh-edm.com/mpc/wp-content/uploads/2015/07/hmi1-1.jpg)
HMI example for a reversing 6-Hi copper mill
![HMI example in local language for a non-reversing 6-Hi aluminium cold mill](http://www.tdh-edm.com/mpc/wp-content/uploads/2016/08/hmi2.png)
HMI example in local language for a non-reversing 6-Hi aluminium cold mill
![HMI example for a non-reversing aluminium universal mill](http://www.tdh-edm.com/mpc/wp-content/uploads/2015/07/hmi3.png)
